6” & 2″ XXS butt weld end mud gate valves NOV ANSON – New
20ea 6” x 5” 7500psi – 6” XXS butt weld end mud gate valve NOV (ANSON).
Specifications
Make: National Oilwell Varco (Anson)
Part no.: A37701‐3
Drawing no.: A8681 Rev. B
The mud valve shall having following specification:
Temperature class: P + U (‐29 to 121 ᵒC)
PSL: 3
PR: 2
Working pressure: 7500 psi
Hydrostatic seat test pressure: 7500 psi
Hydrostatic body test pressure: 11250 psi
Super trim: NACE MR‐01‐75 compatible
Body bore diameter: 4.9”
9ea 2” 7500psi – 2” XXS butt weld end mud gate valve NOV (ANSON).
Specifications
Make: National Oilwell Varco (Anson)
Part no.: A30455‐3
Drawing no.: A6574 Rev. F
The mud valve shall having following specification:
Temperature class: P + U (‐29 to 121 ᵒC)
PSL: 3
PR: 2
Working pressure: 7500 psi
Hydrostatic seat test pressure: 7500 psi
Hydrostatic body test pressure: 11250 psi
Super trim: NACE MR‐01‐75 compatible
Body bore diameter: 1.5”
New Surplus Anson NOV Valves A37701‐3 & A30455-3
